Công tắc Elettrotec PPC | Elettrotec PPCF | Công tắc áp suất PPCF300 150-300bar

Thông số kỹ thuật của công tắc áp suất PPC / PPCF:
Switch rating    3(2)A / 250Vac
Electrical connection    DIN 43650 PG09
Adjusting range    30..150 bar; 150…300 bar
Max static pressure    600 bar
Hysteresis    30% set-point adjustment
Operating temperature    -5C … +80C
Contact (without pressure)    SPDT
Body material    Anodized aluminium Flange: Zinc-plated steel
Piston seal    NBR (standard) – HNBR – FKM – Silicon
Threads    G1/4 male or female
Protection    IP65
Mechanical life    106 operations
Size    Body 30×30 + connector 37×30 Height 72mm; with connector max. 92mm
Certifications and Approvals    CE, RINA, Lloyds Register, ATEX, UR
Options    Set-point adjustment rising Set-point adjustment falling Gold contacts.
