Safety Exhaust Automatic Drain Valves

Automatic Drain Valves are an important safety feature for compressed air applications with downstream pneumatic equipment.

A conventional shut off valve can trap compressed air in pneumatic equipment, which could create a potentially dangerous situation. Lance Safety Exhaust Automatic Drain Valves allow the down stream pressure to be released when the valve is in the closed, “off” position.

Valve Design Features

• Blowout proof stem
• Adjustable packing gland
• Glass reinforced Teflon seats
• NPT end connections
• 2 Piece construction
• Standard Stainless Steel Ball & Stem
• Drilled vent port
• Drilled vent hole in ball

Pressure Ratings: Size & Max PSI

• 1/4″, 3/8″, 1/2″: 300 Max PSI
• 3/4″, 1″: 175 Max PSI
• 1-1/4″, 1-1/2″, 2″, 2-1/2″, 3″, 4″: 150 Max PSI

Common Valve Options Available

• Handles: Locking, Oval, Tee, Extensions, Lockable Extensions
• Handle Extensions: 1-1/4″, 2-1/4″, 3-1/4″. We also offer a full range of over 40 options, please contact us for more details.
• Lockable Extensions: 2-1/4
• Seats: Graphite reinforced Teflon for highertemperature applications

*Mounting pad not available on SS styles
